The drawing of loading gauge TCDD uses in its rail network.

There are 4 different loading gauge schemas according to “Network Statement 2017” in Turkey.

(a) is the general loading gauge, (b) and (c) are mainly is for traffic to Europe and (d) is mainly for Iran traffic after Van.

TCDD Loading Gauge
