Axle Load in Turkish Railways

Turkish railway map showing max axle loads permitted.

A great part of the Turkish railways is 20 to/axle (C-class) or 22.5 to/axle (D-class) kullanılmakta.

Map is prepared as of end of 2012.

Non-color lines have lower capacity.

Axle Load Map on Turkish Rail Network
